Solenoid Valve INDFOS IMVD-10

Solenoid Valve INDFOS IMVD-10

INDFOS 2/2 NC, Solenoid Valve 1/2″” with 220V AC Coil
SWITZER WSV 10 / INDFOS IMVD 10



Application/Type Solenoid Valve
Enclosure (Housing) Type Nil
On/Off Differential Type Nil
Sensor Type Nil
Sensor Material Nil
Micro Switch Nil
Micro Switch Rating Nil
Process Connection 1/2″ BSP (M)
Pressure Range Nil
Categories: ,

Description

1. Valve Type : 2/2 Normally Closed (NC)
2. Service : Liquids (Oil / Water) and Gasses (Air / Methane / Town Gas / Butane / Propane)
3. Size : 1/2″” BSP M
4. Oriface : 10mm
5. Operating Pressure : Liquids & Gasses : Max 17 Bar
6. Minimum Operating Differential Pressure : 0.05 Bar
7. Medium Temperature : (-) 10 to 90 Deg C
8. Ambient Temperature for Coil : 40 Deg C
9. Kv Factor : 1.5
10. Test Pressure : 50 Bar
11. Coil Voltage : 220V 50Hz AC (+/-) 10% ; 8W
