Description
1. Switch Type : Pressure
2. Sensor Type : SS 316 L Diaphragm
3. Wetted Parts : SS 316
4. Enclosure : Aluminium Pressure Die Cast Weatherproof To Ip:66
5. On/Off Differential : Fixed Within 6 – 10% Of F.S.R.
6. Range : 0.2 to 1.6 Bar
7. Maximum Working Pressure : 60 Bar
8. Process Connection : 1/4″” NPT (F)
9. Micro Switch : 1x SPDT (1 NO + 1 NC)
10. Micro Switch Rating : AC Rating — 15A, 250V / DC Rating — Resistive : 0.5A 110V / 0.25A 220V / 8A 24V
11. Electrical Entry : 1/2″” NPT (F)
12. Maximum Fluid Temperature : 170 Deg C
