Description
1. Switch Type : Pressure
2. Sensor Type : SS 316 L Diaphragm
3. Wetted Parts : SS 316
4. Enclosure : Aluminium Pressure Die Cast, Weatherproof And Flameproof To Gr.Iia, Iib Or Iic
5. On/Off Differential : Fixed
6. Range : 10 to 40 Bar
7. Maximum Working Pressure : 110 Bar
8. Process Connection : 1/4″ NPT (F)
9. Micro Switch : 1x SPDT (1 NO + 1 NC)
10. Micro Switch Rating : AC Rating — 5A, 250V / DC Rating — Resistive : 0.4A 110V / 0.2A 220V / 2A 24V
11. Electrical Entry : 1/2″ NPT (F)
12. Maximum Fluid Temperature : 110 Deg C
